| 입력 전압: | 3.0-3.4V | 빛나는 효능: | 240 lm/w |
|---|---|---|---|
| 빛나는 플럭스: | 240-280lm; 350-400lm | 힘: | 3W, 4W |
| 보기 각도: | 120 ° | 색상 렌더링 인덱스: | 70/80/90/95 |
| 작동 온도: | -20-100 ℃ | 저장 온도: | -20-80 ℃ |
| 크기: | 3.5*3.5mm | 현재의: | 700mA;1000mA |
| 칩 재료: | 잉간 | 기판: | 세라믹 |
| 칩 크기: | R3.0MM | 광학 감쇠: | 0.1% |
| 제품 체중: | 0.01kg | ||
| 강조하다: | Sanan SMD3535 LED chip 3W white,ceramic substrate LED chip 4W,120° viewing angle SMD LED |
||
| Color Temperature (CCT) | 2700K (Soft Warm White), 3500K (Warm White), 4100K (Neutral White), 5000K (Daylight), 6000K (Daylight Alert) |
| Input Voltage | 3.0-3.4V |
| Warranty | 2-Year |
| Type | SMD LED |
| Support Dimmer | Yes |
| Lighting Solutions Service | Lighting and circuitry design, LitePro DLX layout, auto CAD layout |
| Luminous Efficacy | 240 lm/w |
| Lifespan | 2 years |
| Product Weight | 0.01 kg |
| Chip Material | INGAN |
| Emitting Color | White |
| Luminous Flux | 240-280LM; 350-400LM |
| Power | 3W, 4W |
| Viewing Angle | 120° |
| Color Rendering Index (Ra) | 70/80/90/95 |
| Operating Temperature | -20°C to 100°C |
| Storage Temperature | -20°C to 80°C |
| Substrate | Ceramic |
| Size | 3.5*3.5MM |
| Chip Brand | SANAN 55mil/SANAN 45mil |
We accept OEM and ODM service to customize any type of LED chip.
